Dual Plate Wafer Check Valve – YONCO High-Performance Non-Return Valve
The YONCO Dual Plate Wafer Check Valve is an advanced, multi-purpose non-return valve that is significantly stronger, lighter in weight, and smaller in size compared to conventional swing check valves. Engineered with a spring-loaded dual-plate design, it ensures an incredibly fast response to flow reversal, effectively eliminating water hammer and ensuring silent operation. It is the ideal space-saving solution for water supply, oil, gas, and chemical processing pipelines.
Core Features & Advantages
- Compact Wafer Design: The short face-to-face dimension allows for easy installation between flanges in tight spaces, reducing piping support requirements and installation costs.
- Water Hammer Prevention: The dual-plate structure is spring-assisted, allowing the valve to close almost instantaneously as the flow velocity decreases, preventing slamming and pressure surges.
- Zero Leakage Performance: Precision-machined seats (available in EPDM, NBR, or Viton for soft sealing; Stellite for hard sealing) ensure a bubble-tight shut-off.
- Low Pressure Drop: The streamlined internal flow path and independent plate action minimize turbulence and energy loss.
- Versatile Mounting: Can be installed in both horizontal and vertical upward flow orientations.
Technical Specifications
| Parameter | Specifications & Standards |
|---|---|
| Design Standard | API 594, ASME B16.34 |
| Size Range | DN40 – DN1200 (1.5″ – 48″) |
| Pressure Rating | PN10, PN16, PN25, PN40 (Class 150 – 300) |
| Body Material | Cast Iron, Ductile Iron, WCB, LCB, SS304, SS316 |
| Disc Material | Aluminum Bronze, SS304, SS316, Duplex Steel |
| Seat Options | EPDM, NBR, Viton, Metal Seat (Stellite Overlay) |
| Test Standard | API 598 |
Primary Applications
• Water Treatment & Desalination
• HVAC & Cooling Water Systems
• Oil & Gas Refineries
• Pulp & Paper Production
• Chemical Processing Plants
• Marine & Shipbuilding
Reliable Wafer Solutions by YONCO
Efficiency and reliability are at the core of YONCO‘s engineering. Our dual plate wafer check valves are 100% pressure tested and offer a superior service life even in demanding industrial environments. Need a specific material combination or a high-pressure rating? Our technical team is ready to provide a customized solution.
